WiTricity wireless EV charger
- Power Output: Up to 11 kW
- Charging Levels: Equivalent to Level 2 AC
- Supported EV Standards: SAE J2954 (wireless EV charging)
- Installation Type: Ground pad
PROS
- Cable-free charging – just park over the pad, no plugging/unplugging.
- Comparable speed to Level 2 charging (up to 11 kW).
- High efficiency (up to 93% grid-to-battery).
- Standardization (SAE J2954) ensures future EV compatibility.
- Scalable technology – supports 3.3 kW, 6.6 kW, and 11 kW setups.
- Future-proof – enables autonomous vehicle self-charging.
CONS
- Not commercially available to consumers yet (mostly pilot/OEM use).
- Unclear pricing – could be more expensive than plug-in chargers.
- Installation complexity (requires ground pad integration).
- Some specs not publicly detailed (IP rating, cooling, UI, etc.).
- Slightly lower efficiency vs wired charging (few % loss).
recommmened
Full Specifications
General for EV Charging Station
| Model | WiTricity 11 kW Wireless EV Charger (reference design) |
| Manufacturer | WiTricity Corporation |
| Launch Date | Ongoing (technology demonstrated, not sold as consumer unit) |
| Status | Prototype / Pilot deployments, OEM licensing |
| Country of origin | United States |
EV Charging Station Performance
| Power Output (kW) | Up to 11 kW |
| Voltage (V) | 220–240 V (AC input) |
| Charging Levels | Equivalent to Level 2 AC |
| Charging Speed | Similar to 11 kW Level 2 charging (~30–35 miles of range per hour; ~5–6 h for 60 kWh battery) |
Compatibility
| Connector Type(s) | Wireless pad |
| Supported EV Standards | SAE J2954 (wireless EV charging) |
| Vehicle Communication Protocols | Short-range comm (alignment, power negotiation), WiFi supported in reference design |
Electrical / Installation
| Input Power Requirements | 220–240 V AC (single/three phase depending on design) |
| Efficiency | 88–93% (grid-to-battery), coil-to-coil up to 98% |
| Onboard Conversion | Integrated AC/DC and DC/AC modules in pad + vehicle receiver |
Safety & Compliance
| Certifications | FCC, CISPR, ICNIRP compliance (EM field safety) |
| Standards | SAE J2954, IEC/ISO in progress |
Smart Features
| Connectivity | WiFi (pad communication) |
| Smart Charging | Supported in principle (power negotiation, scheduling possible) |
Environmental & Physical
| Installation Type | Ground pad (flush/surface-mounted); vehicle receiver installed undercarriage |
| Cabin Type | N/A (wireless system) |
